Description
Key Features
Smart controller
- Time dimming mode, so you can set how the lamp dims through the night
- IP68 rated
- Protection against overcharge, over-discharge and short circuit
LED chips
- SMD3030 chips, 42 per module
- Efficiency of 160-180lm/W
- Lifespan over 100,000 hours
Lithium battery
- Class A LiFePO4 cells
- Up to 2000 charge cycles
- Lifespan over 10 years
- 3-year warranty
Solar panel
- Class A monocrystalline
- Efficiency over 21%
- Lifespan of 25 years
- Supports horizontal and vertical installation
General Specifications
| Specification | Details |
|---|---|
| Series | SOLARA S04 / S04 PRO |
| Product Type | AIO (all-in-one) solar street light |
| Controller | Smart controller with time dimming |
| Light Source | SMD3030 LED, 42 chips per module |
| Light Efficiency | 160-180lm/W |
| CRI | Ra > 70 |
| CCT | 3000-6500K |
| LED Lifetime | > 100,000 hours |
| Battery | Class A LiFePO4 |
| Solar Panel | Class A monocrystalline, efficiency > 21% |
| Charge Time | 4-6 hours |
| Light Time | 20-24 hours / 3-5 nights |
| Operating Temperature | -20°C to +60°C |
| IP Rating | IP68 |
Model Range
| Model | Solar Panel | Battery (Wh) | Lamp Size (mm) | Package (mm) | Net Weight |
|---|---|---|---|---|---|
| BST-AI0-2520P-S04 | 25W | 70 | 631 x 244 x 50 | 710 x 325 x 120 | 3.6kg |
| BST-AI0-3530P-S04 | 35W | 120 | 900 x 244 x 50 | 980 x 325 x 120 | 5.1kg |
| BST-AI0-4540P-S04 / S04 PRO | 45W | 150 / 153.6 | 1171 x 244 x 50 | 1250 x 325 x 120 | 6.4kg |
| BST-AI0-6060P-S04 / S04 PRO | 60W | 200 / 230.4 | 1371 x 244 x 50 | 1450 x 325 x 120 | 7.3kg |
| BST-AI0-7080P-S04 / S04 PRO | 70W | 230 / 307.2 | 900 x 416 x 50 | 980 x 500 x 120 | 8.2kg |
| BST-AI0-100100P-S04 / S04 PRO | 100W | 300 / 384 | 1171 x 416 x 50 | 1250 x 500 x 120 | 9.3kg |
| BST-AI0-120120P-S04 / S04 PRO | 120W | 370 / 460.8 | 1371 x 416 x 50 | 1450 x 500 x 120 | 10.5kg |
| BST-AI0-150150P-S04 / S04 PRO | 150W | 460 / 614.4 | 1633 x 416 x 50 | 1713 x 500 x 120 | 11.4kg |
